• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pitch Diameter (B)	4.1
Pitch Diameter (A)	3.6
Outside Diameter (in)	4.15 in
Pulley Material	Cast Iron
Number of Grooves	1
Model Name	1AB_LG_Sheavemaster
Datum Diameter (A)	3.4
Bushing Used	SH
Datum Diameter (B)	3.8
Material	Cast Iron
Bore (Min) (in)	0.5 in
Belt Section	A, B
Product Type	Multiple Sheaves
Number of Hubs	1
Bore Type	QD Bushed
Bushing Bore Range	.500 - 1.625
Pulley Construction	Solid
Face Width (in)	0.875
Overall Width (in)	1.46875

General Specifications

UPC	662289342587
Weight	1.56 LB
Packaged Length	4.40 IN
Packaged Width	4.30 IN
Packaged Height	1.00 IN
