• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Outside Diameter (in)	3.95 in
Pitch Diameter (B)	3.9
Datum Diameter (B)	3.6
Model Name	1AB_LG_Sheavemaster
Number of Grooves	1
Pulley Material	Cast Iron
Pitch Diameter (A)	3.4
Material	Cast Iron
Datum Diameter (A)	3.2
Bushing Used	SH
Belt Section	A, B
Product Type	Multiple Sheaves
Bore (Min) (in)	0.5 in
Bore Type	QD Bushed
Bushing Bore Range	0.500 - 1.625

General Specifications

UPC	662289412556
Weight	1.30 LB
Packaged Length	4.06 IN
Packaged Width	4.06 IN
Packaged Height	1.88 IN
