• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Datum Diameter (A)	13.2
Datum Diameter (B)	13.6
Outside Diameter (in)	13.88 in
Pulley Material	Cast Iron
Number of Grooves	1
Material	Cast Iron
Pitch Diameter (B)	13.9
Bushing Used	SDS
Model Name	1AB_LG_Sheavemaster
Pitch Diameter (A)	13.4
Bore (Min) (in)	0.5 in
Belt Section	A, B
Product Type	Multiple Sheaves
Number of Hubs	1
Bore Type	QD Bushed
Overall Width (in)	1.53125
Pulley Construction	Spoke
Bushing Bore Range	.500 - 2.000
Face Width (in)	1

General Specifications

UPC	662289366903
Weight	16.06 LB
Packaged Length	14.50 IN
Packaged Width	14.50 IN
Packaged Height	1.90 IN
