• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Bushing Used	SDS
Pitch Diameter (B)	12.7
Pitch Diameter (A)	12.2
Number of Grooves	1
Datum Diameter (A)	12
Datum Diameter (B)	12.4
Outside Diameter (in)	12.68 in
Material	Cast Iron
Model Name	1AB_LG_Sheavemaster
Pulley Material	Cast Iron
Product Type	Multiple Sheaves
Bore (Min) (in)	0.5 in
Belt Section	A, B
Bore Type	QD Bushed
Bushing Bore Range	0.500 - 2.000

General Specifications

UPC	662289396924
Weight	13.80 LB
Packaged Length	12.75 IN
Packaged Width	12.75 IN
Packaged Height	1.75 IN
