• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Product Type	Gearbelt Pulley
Width (mm)	19.05 mm
Number of teeth	19
Bore Range	3/8 to 1
Model Name	GBPulley_Master6
Material	Steel
Bore Type	Bushed Bore
Outside Diameter (mm)	56.8452 mm
Outside Diameter (in)	2.238 in
Belt Section	L
Flange (in)	2.50 in
Pitch Diameter (in)	2.268 in
Width (in)	0.75 in
Face Width	1
Hub Diameter (in)	2 in
Number of Hubs	1
Length Through Bore	1.026
Hub Projection	0.74
Pulley Construction	Solid
Overall Length (in)	1.735 in
With Flanges	With Flanges

General Specifications

UPC	662289143214
Weight	0.78 LB
Packaged Length	2.60 IN
Packaged Width	2.60 IN
Packaged Height	1.30 IN
HTC	8483.50.9080
Country of Origin	United States of America
