• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Product Type	Gearbelt Pulley
Model Name	GBPulley_Master2
Bore Range	5/8 to 7/8
Width (mm)	19.05 mm
Number of teeth	19
Bore Type	Rough Bore
Material	Steel
Flange (in)	2.5 in
Outside Diameter (in)	2.238 in
Width (in)	0.75 in
Outside Diameter (mm)	56.8452 mm
Belt Section	L
Pitch Diameter (in)	2.268 in
Face Width	1
With Flanges	With Flanges
Number of Hubs	1
Hub Projection	0.5
Length Through Bore	1.5
Hub Diameter (in)	1.6875 in
Pulley Construction	Solid
Bore Diameter (in)	0.5 in
Overall Length (in)	1.5 in

General Specifications

UPC	662289314256
Weight	1.78 LB
Packaged Length	3.30 IN
Packaged Width	3.00 IN
Packaged Height	1.90 IN
HTC	8483.50.9080
Country of Origin	United States of America
