• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Width (mm)	9.525 mm
Product Type	Gearbelt Pulley
Bore Range	1/4 to 1/2
Number of teeth	18
Bore Type	Rough Bore
Material	Aluminium
Pitch Diameter (in)	1.146 in
Outside Diameter (in)	1.126 in
Outside Diameter (mm)	28.6004 mm
Belt Section	XL
Flange (in)	1.3750 in
Width (in)	0.375 in
Face Width	0.5625
Bore Diameter (in)	0.25 in
Overall Length (in)	0.8125 in
With Flanges	With Flanges
Number of Hubs	1
Pulley Construction	Solid
Hub Diameter (in)	0.8125 in
Hub Projection	0.25
Length Through Bore	0.8125

General Specifications

UPC	662289172030
Weight	0.10 LB
Packaged Length	2.80 IN
Packaged Width	2.40 IN
Packaged Height	1.50 IN
HTC	8483.50.9080
Country of Origin	United States of America
