• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Product Type	Gearbelt Pulley
Width (mm)	50.8 mm
Bore Range	1 to 2 1/4
Number of teeth	18
Material	Ductile Iron
Bore Type	Rough Bore
Flange (in)	5.556 in
Outside Diameter (in)	4.903 in
Width (in)	2 in
Outside Diameter (mm)	124.5362 mm
Belt Section	XH
Pitch Diameter (in)	5.013 in
Face Width	2.5625
Length Through Bore	3.4375
Pulley Construction	Solid
Number of Hubs	1
Hub Diameter (in)	3.6875 in
Bore Diameter (in)	1 in
Overall Length (in)	3.4375 in
With Flanges	With Flanges
Hub Projection	0.875

General Specifications

UPC	662289212866
Weight	13.31 LB
Packaged Length	6.40 IN
Packaged Width	6.40 IN
Packaged Height	4.60 IN
HTC	8483.50.9080
Country of Origin	United States of America
