• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Bore Range	1/2 to 2 5/8
Number of teeth	18
Width (mm)	50.8 mm
Product Type	Gearbelt Pulley
Material	Steel
Bore Type	Bushed Bore
Pitch Diameter (in)	5.013 in
Outside Diameter (in)	4.903 in
Belt Section	XH
Outside Diameter (mm)	124.5362 mm
Width (in)	2 in
Inside Diameter (in)	3.125 in
Flange (in)	5.5625 in
Face Width	2.5625

General Specifications

UPC	662289346097
Weight	7.67 LB
Packaged Length	6.30 IN
Packaged Width	6.30 IN
Packaged Height	4.60 IN
HTC	8483.50.9080
Country of Origin	United States of America
