• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Model Name	GBPulley_Master2
Width (mm)	25.4 mm
Bore Range	5/8 to 1 3/8
Number of teeth	18
Product Type	Gearbelt Pulley
Material	Steel
Bore Type	Rough Bore
Outside Diameter (mm)	71.3994 mm
Outside Diameter (in)	2.811 in
Width (in)	1 in
Pitch Diameter (in)	2.865 in
Belt Section	H
Flange (in)	3.100 in
Face Width	1.3125
Bore Diameter (in)	0.625 in
Overall Length (in)	2 in
Length Through Bore	2
Number of Hubs	1
Hub Diameter (in)	2.25 in
Pulley Construction	Solid
With Flanges	With Flanges
Hub Projection	6.875

General Specifications

UPC	662289122547
Weight	2.88 LB
Packaged Length	3.30 IN
Packaged Width	3.40 IN
Packaged Height	3.20 IN
HTC	8483.50.9080
Country of Origin	United States of America
