• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Number of teeth	17
Width (mm)	19.05 mm
Bore Range	0.625
Product Type	Gearbelt Pulley
Bore Type	Finish Bore
Material	Steel
Outside Diameter (mm)	50.7746 mm
Belt Section	L
Flange (in)	2.25 in
Outside Diameter (in)	1.999 in
Width (in)	0.75 in
Pitch Diameter (in)	2.029 in
Face Width	1
Overall Length (in)	1.5 in
Length Through Bore	1.5
Number of Hubs	1
Pulley Construction	Solid
Hub Projection	0.5
Hub Diameter (in)	1.4375 in
Bore Diameter (in)	0.625 in
With Flanges	With Flanges

General Specifications

UPC	662289181919
Weight	0.93 LB
Packaged Length	3.30 IN
Packaged Width	2.90 IN
Packaged Height	2.00 IN
HTC	8483.50.9080
Country of Origin	United States of America
