• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Product Type	Gearbelt Pulley
Bore Range	3/8 to 1
Number of teeth	16
Width (mm)	38.1 mm
Material	Steel
Bore Type	Bushed Bore
Outside Diameter (mm)	63.2968 mm
Width (in)	1.5 in
Belt Section	H
Outside Diameter (in)	2.492 in
Pitch Diameter (in)	2.546 in
Flange (in)	2.78 in
Face Width	1.75
Hub Projection	0.73525
Pulley Construction	Solid
With Flanges	With Flanges
Length Through Bore	1.026
Hub Diameter (in)	2 in
Overall Length (in)	2.547 in
Number of Hubs	1

General Specifications

UPC	662289193943
Weight	1.91 LB
Packaged Length	3.20 IN
Packaged Width	3.30 IN
Packaged Height	2.20 IN
HTC	8483.50.9080
Country of Origin	United States of America
