• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Width (mm)	12.7 mm
Number of teeth	15
Product Type	Gearbelt Pulley
Model Name	GBPulley_Master3
Bore Range	0.5
Bore Type	Finish Bore
Material	Steel
Flange (in)	2.03125 in
Width (in)	0.5 in
Outside Diameter (mm)	44.704 mm
Outside Diameter (in)	1.76 in
Belt Section	L
Pitch Diameter (in)	1.79 in
Face Width	0.75
Bore Diameter (in)	0.5 in
Pulley Construction	Solid
With Flanges	With Flanges
Hub Diameter (in)	1.34375 in
Overall Length (in)	1.25 in
Hub Projection	0.5
Length Through Bore	1.25
Number of Hubs	1

General Specifications

UPC	662289141708
Weight	0.65 LB
Packaged Length	2.56 IN
Packaged Width	2.56 IN
Packaged Height	1.38 IN
HTC	8483.50.9080
Country of Origin	United States of America
