• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Width (mm)	50.8 mm
Number of teeth	156
Bore Range	7/8 to 3 1/2
Product Type	Gearbelt Pulley
Bore Type	Bushed Bore
Material	Steel
Pitch Diameter (in)	24.828 in
Width (in)	2 in
Belt Section	H
Outside Diameter (mm)	629.2596 mm
Inside Diameter (in)	23.5 in
Outside Diameter (in)	24.774 in
Face Width	2.34375
Overall Length (in)	3.125 in
Length Through Bore	2.75
With Flanges	No Flanges
Pulley Construction	Solid
Hub Diameter (in)	6 in
Number of Hubs	1
Hub Projection	0.78125

General Specifications

UPC	662289345625
Weight	62.65 LB
Packaged Length	24.78 IN
Packaged Width	24.78 IN
Packaged Height	2.38 IN
HTC	8483.50.9080
Country of Origin	United States of America
