• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Number of teeth	14
Bore Range	0.5
Width (mm)	25.4 mm
Product Type	Gearbelt Pulley
Material	Steel
Bore Type	Finish Bore
Outside Diameter (in)	1.641 in
Width (in)	1 in
Belt Section	L
Outside Diameter (mm)	41.6814 mm
Pitch Diameter (in)	1.671 in
Flange (in)	1.90625 in
Face Width	1.25
With Flanges	With Flanges
Overall Length (in)	1.75 in
Hub Diameter (in)	1.125 in
Number of Hubs	1
Bore Diameter (in)	0.5 in
Hub Projection	0.5
Length Through Bore	1.75
Pulley Construction	Solid

General Specifications

UPC	662289314164
Weight	0.79 LB
Packaged Length	3.30 IN
Packaged Width	2.20 IN
Packaged Height	2.10 IN
HTC	8483.50.9080
Country of Origin	United States of America
