• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Bore Range	3/4 to 7/8
Product Type	Gearbelt Pulley
Width (mm)	50.8 mm
Number of teeth	14
Material	Steel
Bore Type	Rough Bore
Outside Diameter (mm)	55.2196 mm
Outside Diameter (in)	2.174 in
Belt Section	H
Flange (in)	2.461 in
Pitch Diameter (in)	2.228 in
Width (in)	2 in
Face Width	2.34375
Hub Projection	0.5625
Hub Diameter (in)	1.625 in
Length Through Bore	2.90625
Bore Diameter (in)	0.75 in
With Flanges	With Flanges
Pulley Construction	Solid
Number of Hubs	1
Overall Length (in)	2.90625 in

General Specifications

UPC	662289112661
Weight	2.34 LB
Packaged Length	3.10 IN
Packaged Width	3.30 IN
Packaged Height	3.20 IN
HTC	8483.50.9080
Country of Origin	United States of America
