• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Number of teeth	14
Product Type	Gearbelt Pulley
Model Name	GBPulley_Master2
Bore Range	5/8 to 7/8
Width (mm)	25.4 mm
Material	Steel
Bore Type	Rough Bore
Width (in)	1 in
Belt Section	H
Flange (in)	2.461 in
Pitch Diameter (in)	2.228 in
Outside Diameter (in)	2.174 in
Outside Diameter (mm)	55.2196 mm
Face Width	1.3125
Hub Diameter (in)	1.625 in
Overall Length (in)	1.875 in
Bore Diameter (in)	0.625 in
Length Through Bore	1.875
Number of Hubs	1
Pulley Construction	Solid
Hub Projection	0.5625
With Flanges	With Flanges

General Specifications

UPC	662289242467
Weight	0.80 LB
Packaged Length	3.30 IN
Packaged Width	3.40 IN
Packaged Height	3.20 IN
HTC	8483.50.9080
Country of Origin	United States of America
