• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pitch Diameter (3V)	4.45
Outside Diameter (in)	4.5 in
Bushing Used	SH
Pulley Material	Cast Iron
Model Name	13V_LG_Sheavemaster
Material	Cast Iron
Number of Grooves	1
Belt Section	3V
Product Type	Multiple Sheaves
Bore (Min) (in)	0.5 in
Bore Type	QD Bushed
Bushing Bore Range	0.500 - 1.625

General Specifications

UPC	662289373437
Weight	2.09 LB
Packaged Length	5.70 IN
Packaged Width	5.60 IN
Packaged Height	1.30 IN
HTC	8483.50.9040
Country of Origin	Mexico
