• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Number of teeth	13
Bore Range	0.375
Product Type	Gearbelt Pulley
Width (mm)	19.05 mm
Bore Type	Finish Bore
Material	Steel
Outside Diameter (mm)	38.6588 mm
Outside Diameter (in)	1.522 in
Width (in)	0.75 in
Flange (in)	1.781 in
Belt Section	L
Pitch Diameter (in)	1.552 in
Face Width	1
Length Through Bore	1.5
Number of Hubs	1
Hub Projection	0.5
Overall Length (in)	1.5 in
With Flanges	With Flanges
Pulley Construction	Solid
Bore Diameter (in)	0.375 in
Hub Diameter (in)	1.125 in

General Specifications

UPC	662289301874
Weight	0.62 LB
Packaged Length	2.20 IN
Packaged Width	3.10 IN
Packaged Height	2.20 IN
HTC	8483.50.9080
Country of Origin	United States of America
