• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Width (mm)	9.525 mm
Number of teeth	10
Bore Range	3/16 to 3/16
Product Type	Gearbelt Pulley
Material	Steel
Bore Type	Rough Bore
Belt Section	XL
Pitch Diameter (in)	0.637 in
Flange (in)	.875 in
Width (in)	0.375 in
Outside Diameter (mm)	15.6718 mm
Outside Diameter (in)	0.617 in
Face Width	0.5625
With Flanges	With Flanges
Bore Diameter (in)	0.1875 in
Hub Diameter (in)	0.4375 in
Pulley Construction	Solid
Hub Projection	0.25
Number of Hubs	1
Overall Length (in)	0.8125 in
Length Through Bore	0.8125

General Specifications

UPC	662289753819
Weight	0.05 LB
Packaged Length	1.30 IN
Packaged Width	2.80 IN
Packaged Height	1.00 IN
HTC	8483.50.9080
Country of Origin	United States of America
