• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Model Name	GBPulley_Master1
Product Type	Gearbelt Pulley
Number of teeth	10
Bore Range	3/16 to 3/16
Width (mm)	9.525 mm
Bore Type	Rough Bore
Material	Aluminium
Belt Section	XL
Outside Diameter (in)	0.617 in
Outside Diameter (mm)	15.6718 mm
Flange (in)	.875 in
Width (in)	0.375 in
Pitch Diameter (in)	0.637 in
Face Width	0.5625
With Flanges	With Flanges
Overall Length (in)	0.8125 in
Hub Diameter (in)	0.4375 in
Bore Diameter (in)	0.1875 in
Hub Projection	0.25
Pulley Construction	Solid
Number of Hubs	1
Length Through Bore	0.8125

General Specifications

UPC	662289192076
Weight	0.02 LB
Packaged Length	2.40 IN
Packaged Width	1.95 IN
Packaged Height	1.25 IN
HTC	8483.50.9080
Country of Origin	United States of America
